| Door Preperation |
Cross bore 2-1/8", Edge bore 1". |
| Backset: |
Adjustable square corner faceplate deadbolt latch
(2-3/8" to 2-3/4"). |
| Door Thickness: |
1-3/8" to 2".
(Extension kit for 2-1/4" thick door is available). |
| Cylinder: |
Solid brass cylinder,
5-pin Schlage keyway. |
| Deadbolt Latch Strike Plate: |
Square Corner Strike Plate 1-1/8" x 2-3/4". |
